产品参数
CPU
Use fifth generation processors such as I3-5005U, I5-5200U, I7-5500U, etc
Memory
1 * NB-DDR3 supports 1333/1600MHz memory, low voltage of 1.35V, and maximum support of 8GB
storage
1 * SATAT3.0 maximum transmission speed of 6.0 Gbps, 1 * MSATA3.0
display
Intel HD Graphics 5500 graphics controller, VGA, HDMI, LVDS supports single display, dual display replication, and dual display expansion, Single display under DOS
audio
Integrated Realtek ALC662 HD digital audio decoder, 6-channel high fidelity audio controller; Support Line In, Line Out, and MIC In interfaces
Ethernet
2 * RTL8111H Gigabit Ethernet card chip, supporting network wake-up and PCIe diskless boot function
I/O interface
2*USB3.0,4*USB2.0
Supports 6 * COM, with COM1 supporting RS232/422/485 optional
1 * SIM card slot, supports SIM card, requires SIM card when using 3G/4G
1 * GPIO control pin
size
165mm*115mm
power supply
DC 12V, Suggest using a 12V4A or higher power supply
operating system
Supports Windows 10, Windows 8, Windows 7, Linux, etc
operation temperature
-20 ℃~60 ℃, air flow
storage temperature
-25℃~75℃
Storage humidity
5%~95% @ 40 ℃, no condensation
